Retro car stereo radio Blaupunkt Frankfurt RCM 82 Bluetooth USB AUX

BLAUPUNKT Frankfurt RCM 82 DAB MP3-Autoradio Bluetooth DAB USB SD iPod AUX-IN Radio
High-End CODEM IV World-tuner
FM, AM, DAB, DAB+ Tuner with radio text/DLS (DAB, DAB+ not available in USA)
Traffic function
Travelstore
Service following
Introscan Presets and Band
Media player
USB (2x), microSD with MP2, MP3, WMA, FLAC, M4A (AAC), APE, WAV Support
Analog audio input on the front (AUX-IN)
Apple iPod Support
Bluetooth
Telephony via int. or ext. microphone
Audio streaming with track info
Audio mix-option for mobile navigation
Voice assistant support (e.g. Siri, Google, Alexa)
Automatically switch on when there is an incoming call (Wake-up on call)
Two phones can be connected at the same time (Twin-Connect)
Phonebook access
Sound
Digital signal processing (DSP)
2x 14-band equalizer (front and rear channels separately adjustable)
Sound presets
Loudness
4-channel pre-amp out + subwoofer preamp output
4 x 50 Watt
General features
Adjustable illumination colour of buttons and display (Vario Colour, 4,096 colours)
2-line display
Brightness control of display and keys (DIM function)
Direct access to all audio sources
Permanent memory
Short body (low installation depth)
IR-remote control option, RC-10 compatible
Steering wheel remote control support (analog SWC input)
Blaupunkt Frankfurt RCM 82 DAB FULL Specification
RADIO ANALOG / DIGITAL features
Tuner Type - High-End Automotive Tuner Blaupunkt CODEM IV
World Tuner (switchable) - EU, USA, South America, Thailand
Frequency bands - FM, AM, DAB, DAB+
Frequency band FM - 87.5 – 108 MHz
Frequency band MW - 531- 1602/ 530- 1710 kHz
Channels (frequency band) DAB/ DAB+ - 5A- 13F (174,928- 239,200 MHz)
Station memory - 15 x FM, 10 x AM, 15 x DAB
Station memory levels deactivatable - FM2, FMT, AM, AMT, DAB2, DAB3
Station display (PS) - Yes
Radiotext/ Radiotext Plus (RT/ RT+) -Yes/ No
Display DLS/ ENSEMBLE/ SERVICE - Yes/ Yes/ Yes
Alternate frequency function (AF) - Yes
Traffic Radio (TA) FM/ DAB - Yes/ Yes
RDS Time (CT) - Yes
Enhanced Oth. Net w. (EON) - Yes
Regional function (REG) - Yes
Program type identifier (PTY) FM/ DAB - Yes/ Yes
PTY Seek FM/ DAB - Yes/ Yes
Travelstore/ Number of Presets for Travelstore - Yes/ 5x FMT, 5x AMT
Band Scan + Preset Scan FM/ DAB - Yes/ Yes
Sensitivity (FM) - Two levels (lo / dx)
Noise suppression (FM) - Yes
Hi-Cut (FM) - Yes (multi-level switchable)
DAB-DAB Service following - Yes
DAB-FM Service following - Yes
Service scan - Yes
Ensemble/ Service selection - Yes/ Yes
Ensemble/ Service browsing - Yes/ Yes
Frequency response FM - 30 – 15.000 Hz +/- 3 dB
Frequency response DAB - 20 – 20.000 Hz +/- 3 dB
MEDIAPLAYER features
AUX front - Yes (3.5 mm jack)
AUX detection / automatic source activation - Yes
USB front - Yes (type A, recessed jack)
USB rear - Yes (type A, cable)
Memory card reader - Yes (microSD, microSDHC, microSDXC)
Concealed front inputs - Yes (USB & microSD usable with flap closed)
Compatible file system (USB, memory cards) - FAT16, FAT32, exFAT
Maximum storage size (USB, memory cards) - > 128 GB
Maximum file/folder count (USB, memory cards) - > 30,000
Playback formats - MP2, MP3, WMA, FLAC, M4A(AAC), APE, WAV
Display options - ID3V2 (title, artist, album), folder, file, playtime
Folder & file browsing - Yes
Scrolling - Yes (single/ continuously)
iPod, iPhone control - Yes (USB front and rear)
Shuffle folder/ media - Yes/ Yes
Repeat Title / Folder/ All - Yes/ Yes/ Yes
Mix / Repeat / Scan - Yes/ Yes/ Yes
BLUETOOTH* features
Phone call - Yes
Internal microphone - Yes
Connectivity ext. microphone - Yes
Answer/ reject call Yes/ Yes
Access phonebook - Yes (max. 1000 numbers)
Audio streaming - Yes
Audio streaming ID3 track display - Yes (Title, Artist, Album, Playtime)
Voice assistant access (e.g. Siri, Google, Alexa) - Yes
Cell phone navigation audio mix - Yes
Auto wake-up on call - Yes (when radio off + ignition on)
Fast pairing without PIN - Yes
Automatic reconnection - Yes
Bluetooth version - 5.0 LE
Number of paired devices - max. last 5
No. of devices connected at the same time - max. 2 (Twin Connect)
Supported profiles - A2DP, AVRCP, HFP, SPP
Audio Codecs - aptX, AAC, SBC
*Availability/support of functions depend on the phone/app used
SOUND features
Equalizer Number of bands/design - 2 x 14/parametric
Bass/treble adjustment - Yes / Yes (+/- 12 steps)
Source specific bass/treble adjustment - Yes
Balance/fader - Yes / Yes (+/- 12 steps)
HPF/LPF - Yes, separately for front/rear channels, variable
Loudness - Yes
Sound Presets - Yes (Rock, Pop, Classical)
Speaker Outputs (Channels) - 4
Preamp Outputs (Channels, Voltage) - 4 (RCA, < 4V)
Max. Power - 4 x 50 watts
Sine power at 14.4 V - 4 x 24 watts (according to DIN 45324)
Sub-Out - 2 (RCA, gain/ frequency variable)
GENERAL features
Display - LCD, negative, anti-reflective, wide-angle 2 lines, Alphanumeric/Symbols
Illumination color display/keys - Vario Colour, 4,096 colors
Day/Night mode - Yes (manual/via dimmer connection)
Brightness - Multi-level, variable
Time display - Yes
HMI languages - English, German
Low standby current - Yes (< 3,5 mA )
Antenna inputs - FM DIN/ ISO, DAB SMB (with 12 V phantom power)
Telephone mute - Yes
Ext. handsfree microphone connector - Yes
Remote control - Yes (IR input for optional RC-10 and card remote)
Steering wheel remote control (SWC) - Yes (analog, programmable, pre-programmed)
Variable scan time - Yes
Confirmation beep - Yes (can be deactivated)
Control panel type - Fixed panel
Color panel/ decor ring - Black/ Black
Software Update - via USB
Permanent Memory - Yes (Settings & Presets)
Demo mode - Yes
Weight - approx. 0.67 kg
Dimensions - 50mm x 178mm x 116mm (H x W x D, housing only) 58mm x 186mm x 10mm (H x B x T, front w/o keys)
Operating voltage - 10.5 – 14.4 V
Power consumption - in operation: < 10A, 10 sec. after ACC power off: < 3.5 mA
